Britlift T13 Modular Spreader Beam | 13 Tonne

From: £869.00Ex. VAT

The Britlift T13 Modular Spreader Beam is a configurable lifting solution designed for safe and efficient load distribution across professional lifting and rigging applications.

Maximum vertical load: 13 tonnes
Available span options from 0.75m to 6.50m in this test import
Modular construction with interchangeable strut configurations
Designed for use by trained and competent riggers or slinger/signallers
Shackles are not included

Hire Me

Green Pin® Bow Shackle SC - Standard bow shackle with screw collar pin

From: £3.14Ex. VAT

Hire from £2.20

The Green Pin®Bow Shackle SC is a bow shackle with a screw collar pin. The screw pin enables quick (dis)assembly which makes the shackle perfect for rigging activities in which assembly and disassembly occur relatively frequently.

- Capacity 0.33t to 55t

- Screw pin for quick (dis)assembly

- Galvanization assures long term durability

Total: £0.00

The Britlift T13 Modular Spreader Beam is a configurable lifting solution designed for safe and efficient load distribution across professional lifting and rigging applications.

Manufactured in the UK, the T13 system uses interchangeable struts to create a range of span configurations, helping reduce the need for multiple fixed-length beams.

Maximum vertical load: 13 tonnes
Available span options from 0.75m to 6.50m in this test import
Modular construction with interchangeable strut configurations
Designed for use by trained and competent riggers or slinger/signallers
Shackles are not included

BRIT-UI2025-T13-USER_INSTRUCTIONS.pdf

45° STV		30° STV		20° STV
SPAN	SWL IN TONNES	MINIMUM TOP SLING LENGTH REQUIRED (METERS)	SWL IN TONNES	MINIMUM TOP SLING LENGTH REQUIRED (METERS)	SWL IN TONNES	MINIMUM TOP SLING LENGTH REQUIRED (METERS)
0.5	13	0.3	13	0.4	13	0.7
0.75	13	0.5	13	0.7	13	1
1	13	0.7	13	0.9	13	1.4
1.25	13	0.9	13	1.2	13	1.7
1.5	13	1	13	1.4	13	2.1
1.75	13	1.2	13	1.7	13	2.5
2	13	1.4	13	1.9	13	2.8
2.25	13	1.6	13	2.2	13	3.2
2.5	13	1.7	13	2.4	13	3.6
2.75	13	1.9	13	2.7	13	3.9
3	13	2.1	13	2.9	13	4.3
3.25	13	2.3	13	3.2	13	4.7
3.5	13	2.4	13	3.4	13	5
3.75	12	2.6	13	3.7	13	5.4
4	11	2.8	13	3.9	13	5.8
4.25	10	3	13	4.2	13	6.1
4.5	9	3.2	13	4.4	13	6.5
4.75	8	3.3	13	4.7	13	6.9
5	7	3.5	12	4.9	13	7.2
5.25	6	3.7	11	5.2	13	7.6
5.5	6	3.9	10	5.4	13	8
5.75	5	4	9	5.7	13	8.3
6	5	4.2	8	5.9	13	8.7
6.25	4	4.4	8	6.2	13	9.1
6.5	4	4.6	7	6.4	11	9.4

THIS IS A SPREADER BEAM AND MUST ONLY BE LOADED AT THE TWO END POINTS THROUGH THE END LINKS. NEVER HANG LOADS FROM THE STRUTS

THIS IS A SPREADER BEAM AND MUST ONLY BE LOADED AT THE TWO END POINTS THROUGH THE END LINKS. NEVER HANG LOADS FROM THE STRUTS.
STV (SLING TO VERTICAL) ANGLE MUST BE NO MORE THAN 45°.
CHART 1 MUST BE REFERRED TO IN ORDER TO ENSURE THAT THIS BEAM IS SUITABLE FOR THE PLANNED LIFT.
END LINKS MUST HANG DOWNWARDS, TOWARDS THE LOAD.
THE WLL (WORKING LOAD LIMIT) OF A SINGLE LINK PLATE IS 6.5 TONNES (13 TONNES COMBINED). DO NOT EXCEED THIS WEIGHT AT ONE END OF THE BEAM.
THE T13 USES M12 x 35 GRADE 8.8 HT BOLTS, NUTS AND WASHERS. THE RECOMMENDED TIGHTENING TORQUE IS 100Nm.
ANY PERSONNEL USING THIS PRODUCT MUST BE A TRAINED AND COMPETANT RIGGER OR SLINGER/SIGNALLER.
THE ONGOING USE OF THIS PRODUCT MUST BE IN ACCORDANCE WITH THE REQUIRMENTS IN LOLER (LIFTING OPERATIONS AND LIFTING EQUIPMENT REGULATIONS 1998).
PLEASE ENSURE THAT NO MORE THAN 6 STRUTS ARE USED IN THE ASSEMBLY OF A BEAM.
CHECK THAT NO RIGGING EQUIPMENT CLASHES WITH THE BEAM. THE BEAM MUST ONLY BE LOADED THROUGH THE SHACKLE PIN HOLES AT EACH END.

Britlift T13 Modular Spreader Beam | 13 Tonne

Name: Britlift T13 Modular Spreader Beam | 13 Tonne
Brand: Britlift
SKU: T13-075
Price: 869.0 GBP
Availability: InStock

From: £869.00Ex. VAT

Est. lead time to dispatch: 1-2 Days

The Britlift T13 Modular Spreader Beam is a configurable lifting solution designed for safe and efficient load distribution across professional lifting and rigging applications.

Maximum vertical load: 13 tonnes
Available span options from 0.75m to 6.50m in this test import
Modular construction with interchangeable strut configurations
Designed for use by trained and competent riggers or slinger/signallers
Shackles are not included
