Camlok CG Standard girder turning clamps

From: £507.37Ex. VAT ~~£563.74~~

The main purpose of the CG girder turning clamps are for the transportation and turning of steel girders (RSJ) through 90°.

Capacities from 100 to 2000 kg
Jaw capacities from 0 to 32 mm
Can be used individually or for longer beams used in pairs in conjunction with a spreader beam

Hire Me

Green Pin® Bow Shackle SC - Standard bow shackle with screw collar pin

From: £3.05Ex. VAT

Hire from £2.20

The Green Pin®Bow Shackle SC is a bow shackle with a screw collar pin. The screw pin enables quick (dis)assembly which makes the shackle perfect for rigging activities in which assembly and disassembly occur relatively frequently.

- Capacity 0.33t to 55t

- Screw pin for quick (dis)assembly

- Galvanization assures long term durability

Total: £0.00

CG Standard girder turning clamps

The main purpose of the CG girder turning clamps are for the transportation and turning of steel girders (RSJ) through 90°.

They can be used individually or for longer beams used in pairs in conjunction with a spreader beam.

The clamps are attached to the horizontal flange of the girder and locked in place by the jaw locking lever. Once lifted the girder will turn through 90°.

CG-MA-EN.pdf

Model	WLL kg*	Jaw capacity mm	Weight kg*
CG 1	100 - 1000	0 - 16	6
CG 2	200 - 2000	0 - 32	14

*Per Clamp

Model	A,mm	B,mm	C,mm	D,mm	E,mm	F,mm	G,mm	H,mm	I,mm
CG 1	211	90	50	13	43	263	64	350	337
CG 2	290	140	80	20	60	317	100	465	435

On Sale

Camlok CG Standard girder turning clamps

Name: Camlok CG Standard girder turning clamps
Brand: Camlok
SKU: CG1-1-1
Price: 507.37 GBP
Availability: InStock

From: £507.37Ex. VAT ~~£563.74~~

Est. lead time to dispatch: 4-5 Weeks

The main purpose of the CG girder turning clamps are for the transportation and turning of steel girders (RSJ) through 90°.

Capacities from 100 to 2000 kg
Jaw capacities from 0 to 32 mm
Can be used individually or for longer beams used in pairs in conjunction with a spreader beam

MODEL | WORKING LOAD LIMIT
