William Hackett WH-L4 Lever Hoist | 800Kg - 15 Tonnes

From: £114.55Ex. VAT ~~£127.28~~

This tough and robust lever hoist can lift or pull and is great for every day use, one-off lifts or as part of a fleet.

WLL 0.258 - 15 tonnes
Twin pawl
Safety factor 4:1

Hire Me

Crosby G-209 Alloy Bow Shackle

From: £6.23Ex. VAT

Hire from £2.20

The Crosby G-209 Screw Pin Anchor Shackle is a trusted choice for lifting, rigging and load-securing applications across construction, industrial, marine and transport environments.

- Sizes available 0.33t to 55t

- Hot-dip galvanized

- Forged, Quenched & Tempered, with alloy pins

Total: £0.00

WH-L4 Lever Hoist

Name: William Hackett WH-L4 Lever Hoist | 800Kg - 15 Tonnes
Brand: William Hackett
SKU: WH-L4-3331586-87
Price: 114.55 GBP
Availability: InStock

The William Hackett L4 Lever Hoist is designed, manufactured and proof load tested in the UK.

This tough and robust lever hoist can lift or pull and is great for every day use, one-off lifts or as part of a fleet. We provide a full range of spare parts and can offer training on safe use and inspection.

The Shipyard Hook adaptation is available on request.

LIGHT LOAD CAPABILITY: the WH L4 is tested and certified at 2% of the lever hoist rated capacity.

TWIN PAWL: double safety; fitted as standard.

SAFETY LATCHES: the WH L4 lever hoist top and bottom hooks are fitted with heavy duty cast steel latches. The latch and hook tips are integrated creating a strong and robust hook closure.

HOOK OVERLOAD AND TRACEABILITY MARKS: hooks have overload indicator marks either side of the hook throat (500kg to 10t). Both top and bottom hooks are embossed with a batch code, manufacturer's mark and the working load limit for full traceability and compliance to international standards.

HOOK HOUSING: secured with socket head cap screws/hex head bolts and nyloc locking nuts to allow full inspection.

FLEETING/CROSS HAULING: the WH L4 lever hoists are tested and certified for fleeting or cross hauling applications up to 45° from the vertical without deration.

LOAD CHAIN: the WH L4 lever hoists are fitted with load chain that fully complies with international standard BS EN818-7 Grade T (8).

OVERLOAD LIMITER: available as an option upon request.

TOP AND BOTTOM HOOK ADAPTORS: available as an option upon request.

TRAVELLING END STOP: available as an option upon request.

MANUFACTURED AND PROOF TESTED in the U.K.

Part Code	WLL tonnes	No. of Falls	Load Chain mm	Standard Lift m	A mm	B mm	C mm	D mm	E mm	H mm	Mass kg	Extra Weight per m kg
33.08	0.8	1	5.6 x 17	1.5	148	121	41.5	265	28	280	6.2	0.7
33.16	1.6	1	7.1 x 21	1.5	165.5	141	52	350	33	350	9.6	1.1
33.32	3.2	1	10 x 30	1.5	194.5	178	61.9	415	42.5	420	15.5	2.2
33.63	6.3	2	10 x 30	1.5	194.5	228	84.3	415	51	570	27	4.4
33.9	9	3	10 x 30	1.5	194.5	310	88	415	56	680	38.3	6.6
033/1500	15	6	10 x 30	1.5	194.5	420	-	415	80	1000	90	13.2
